SkyRC Q200 Neo QUAD LiPo Charger 1-6s 10A 200W AC/DC

SkyRC / SK-100197-01 / Q200 Neo QUAD LiPo Charger 1-6s 10A 200W AC/DC

The Q200neo, like its predecessor, offers four times the performance with astonishing strength and precision. To achieve this, the modern indigo-colored housing includes high-quality components that can achieve a DC charging power of up to 400W - divided among the four channels of the charger, of course. This translates to 100W per channel, allowing for the independent charging of lithium, nickel, and lead-acid batteries. In AC mode, it still delivers an impressive total power of 200W.

In addition to the various charging modes for different types of batteries, this charger is also capable of safely and quickly discharging batteries. The days of discharging batteries overnight are over, as the 25W discharge power reduces the required time from around 6.5 hours to an average of 1.5 hours. This is only possible because the discharge power is more than twice as efficient as the classic Q200.
To make this technology as user-friendly as possible, the Q200neo uses the same new operating system as other current SkyRC chargers. Large icons, different colors, and clear text - these and other visual features make using this charger easy to understand. For those who still prefer computer control, the free "Charger Master" software is available. And even via smartphone, the Q200neo can be conveniently controlled thanks to built-in Bluetooth and the app "."

Whether you are an experienced professional or a passionate hobbyist, the Q200neo ensures that your batteries are always ready for exciting RC adventures. Say goodbye to unnecessary downtime and unlock the limitless potential with the SkyRC Q200neo charger.

Features:

• Much more powerful than the Q200
• Large LCD color display
• Re-peak mode for NiMH/NiCd batteries
• Also ideal for monitoring and measuring batteries
• PC communication: USB connection for PC operation & firmware upgrade
• Smart Phone operation & display with built-in Bluetooth module
  Additional smartphones with the optionally available PD3.0

Specifications:

• Input Voltage: AC: 100-240V / DC: 10-30V
• Charge Power DC: max. 400W (4x 100W)
• Charge Power AC: max. 200W (dynamically distributed)
• Discharge Power: 5W (main port) / max. 25W (balance port, LiPo/6S)
• Charge Current: 0,1 - 10A (4x)
• Discharge Current: 0.1 - 2.0A (4x)
• Balance Current: max. 800mA / cell
• Display: 2.8'' TN-Display, 240x320px, 262k colors
• Case Material: PC-ABS V0
• Max. Cells: LiPo/LiHV/LiFe/LiIon: 1-6 cells / NiMH/NiCd: 2-15 cell / Pb: 2-20V
• Weight: 680g
• Dimensions: 123x119x78mm

Delivery:

• 1x Q200 NEO Charger
• 1x Manual
• 1x AC power cord

MANUAL

Specifications:

Size and Weight





Case Material: PC-ABS V0
Case Size: 123*119*78mm
Weight: 680g
